Specifications

Description

Standards

EEE 802.11n, 802.11g, 802.11b, 802.3, 802.3u, 802.1X (security authentication), 802.1Q (VLAN), 802.11i (WPA2 security), 802.11e (wireless QoS), IPv4 (RFC 791), IPv6 (RFC 2460)

Ports

Ethernet, Power

Switch

Power button (on/off)

Buttons

Reset

Cabling type

Category 5e or better

LEDs

Power, Wireless, LAN

Operating system

Linux

Physical Interfaces

Ports

Gigabit Ethernet, 12V DC power with support for 802.3af PoE

Power supply

Not included with access point, but supports external power 12V DC power jack (Energy Star 2.0 compliant with Efficiency Level 5) and 802.3af PoE

Buttons

Power (on/off) push button; Reset button

Lock slot

Slot for Kensington lock

LED

Power, Wireless, Ethernet

Physical Specifications

Physical dimensions (W x D x H)

6.66 x 6.67 x 1.38 in. (169.08 x 169.42 x 35 mm)

Weight

0.606 lb or 275g

PoE

PoE

802.3af

Peak PoE power

10.6W

Network Capabilities

Network protocols

IEEE 802.11n, 802.11g, 802.11b, 802.3, 802.3u, 802.1X (security authentication), 802.1Q (VLAN), 802.11i (WPA2 security), 802.11e (wireless QoS), IPv4 (RFC 791), IPv6 (RFC 2460), RADIUS, syslog, HTTP/HTTPS, Simple Network Management Protocol (SNMP)

VLAN support

Yes

Number of VLANs

1 management VLAN plus 8 VLANs for SSID

Multiple SSIDs

8

802.1X supplicant

Yes

802.11d

No

SSID to VLAN mapping

Yes

Auto channel selection

Yes

Spanning tree

Yes

Load balancing

Yes

IPv6

Yes

Layer 2

802.1Q-based VLANS, 8 active VLANS plus 1 management VLAN

Security

WEP/WPA/WPA2

Yes, including Enterprise authentication

Access control

Yes, management access control list (ACL) plus MAC ACL

Secure management

HTTPS

Wi-Fi Protected Setup (WPS)

Yes (soft WPS, no hardware push button)

SSID broadcast

Yes

Rogue access point detection

Yes

Mounting and Physical Security

Multiple mounting options

Desktop installation; mounting bracket included for easy ceiling or wall mounting

Physical security lock

Kensington lock slot

Quality of Service

Quality of service (QoS)

Wi-Fi Multimedia Traffic Specification (WMM TSPEC)

Performance

Wireless throughput

Data rate =300 Mbps; actual client throughput will vary.

Recommended user support

Up to 32 connective users, 20 active users

Configuration

Web user interface

Built-in web user interface for easy browser-based configuration (HTTP/HTTPS)

Multi-Access Point Management

Single Point Setup

Yes

Maximum access points per cluster

8

Active clients per cluster

80

Management

Management protocols

Web browser, SNMP v3, Bonjour

Remote management

Yes

Event logging

Local, remote syslog, email alerts

Network diagnostics

Logging and packet capture

Web firmware upgrade

Firmware upgradable through web browser, imported/exported configuration file

Dynamic Host Configuration Protocol (DHCP)

DHCP client

IPv6 host

Yes

HTTP redirect

Yes, and captive portal

Wireless

Frequency

Selectable-band 2.4 GHz or 5 GHz (not concurrent)

Radio and modulation type

Single radio, orthogonal frequency division multiplexing (OFDM)

WLAN

802.11n

Operating channels

1 to 13 (depending on country)

Wireless isolation

Wireless isolation between clients

External antennas

None

Internal antennas

Internal fixed PIFA antenna

Antenna gain in dBi

2 dBi each antenna

Transmitted output power

Receiver sensitivity

Wireless Distribution System (WDS)

Yes

Roaming

Yes

Fast roaming

802.11i preauthentication

Active WLAN clients

Same as number of users: 32 max connected users, 20 active users recommended

Multiple SSIDs

8

Wireless VLAN map

Yes

WLAN security

Yes

Wi-Fi Multimedia (WMM)

Yes, with automatic power save, and Voice profile

Operating Modes

Access point

Access Point mode, WDS bridging, Workgroup Bridge mode
